SATO WM8430031 M84PRO (3) Barcode Label Printer 305DPI, 4.4 inch, 8IPS, Serial RS232C
SATO WM8430031 M84PRO (3) Barcode Label Printer 305DPI, 4.4 inch, 8IPS, Serial RS232C
SATO WM8430031 M84PRO (3) Barcode Label Printer 305DPI, 4.4 inch, 8IPS, Serial RS232C
SATO WM8430031 M84PRO (3) Barcode Label Printer 305DPI, 4.4 inch, 8IPS, Serial RS232C

SATO WM8430031 M84PRO (3) Barcode Label Printer 305DPI, 4.4 inch, 8IPS, Serial RS232C

Sold out
$1,325.00
Allows user to switch print resolution simply by changing printheads.

The M84Pro(3) delivers 4.1" print width at rapid 10 ips with virtually Zero-Compile time by using the latest generation of 32-bit RISC 133 MHz CPU. The M84Pro(3) has a 305 dots-per-inch print resolution, which can be changed to either 203 or 609 dpi simply by switching printheads. All resolutions support the full 4.1" print width. All SATO Pro Series printers come with a minimum of 16MB RAM and 2MB Flash for storage of forms, fonts and graphics. Optional Flash module or PCMCIA memory card expands the printer storage capabilities even further. The M84Pro(3) is available with a vast array of interface connection plug-in modules making integration connectivity issues disappear.

Technical Information

  • Maximum Mono Print Speed: 8 in/s
  • Maximum Print Resolution: 305 dpi
  • Maximum Print Width: 4.10"
  • Recommended Use: Label Print
  • Barcode Symbology Supported:
    • UPC-A
    • UPC-E
    • ITF-14
    • UCC/EAN 128
    • Code 128
    • Interleaved 2 of 5
    • Code 39
    • RSS
    • POSTNET
    • EAN-13
    • EAN-8
    • MSI
    • Codabar
    • Bookland
    • Matrix 25
    • Data Matrix
    • Maxi Code
    • PDF-417
    • QR Code
    • Micro PDF-417

General Information

  • Product Type: Direct Thermal/Thermal Transfer Printer
  • Product Series: Pro
  • Brand Name: Sato
  • Manufacturer: Sato Corporation
  • Product Model: M84Pro(3)
  • Product Name: M84Pro(3) Thermal Label Printer

Physical Characteristics

  • Height: 13.4"
  • Width: 10.4"
  • Depth: 17.1"

Interfaces/Ports

  • Serial Port: Yes

Media Types & Handling

  • Maximum Label Width: 5"
  • Maximum Label Length: 32.80"
  • Media Type:
    • Roll Fed
    • Fanfold
    • Die-cut Label
    • Continuous Form
    • Direct Thermal Paper
    • Thermal Transfer Label
    • Synthetic Media
    • Tag Stock
    • Black Mark
    • Notched
  • Media Sensor:
    • Reflective Media Sensor
    • Transmissive Media Sensor
  • Maximum Roll Diameter: 8.60"

Other

  • Platform Supported: PC
  • Certifications & Standards:
    • CE
    • UL
    • CSA
    • TÜV
  • Additional Information:
    • Adjustable transmissive sensor for gap
    • Reflective sensor for black mark
    • Automatic programmable setting of top of form
    • Label present sensor

Power Description

  • Input Voltage:
    • 110 V AC
    • 220 V AC

Memory

  • Standard Memory: 16 MB
  • Flash Memory: 2 MB
